An EV charger, also called Electric Vehicle Supply Equipment (EVSE), connects an electric vehicle to an electrical supply and manages the charging connection. A complete installation therefore involves much more than mounting a charger on a wall.

A typical installation may include an electrical distribution board, circuit protection, earthing, cables, connectors, a charger unit, communication equipment, mounting hardware, and measurement or testing instruments.

How an EV Charger Installation Works

The basic process begins with checking the available electrical supply and determining whether it can support the selected charger.

The installer then plans the cable route, protective equipment, mounting location, earthing arrangement, and required isolation points. After installation, electrical tests are performed before the charger is placed into normal operation.

A simplified setup includes:

• Electrical supply: Provides electricity to the charging system.

• Protection equipment: Helps protect the circuit against selected electrical faults.

• Cable and conduit: Carries electricity between the distribution point and charger.

• EV charger: Controls the transfer of electrical energy to the vehicle.

• Connector: Provides the physical connection between charger and vehicle.

• Earthing system: Provides a protective electrical path under fault conditions.

• Communication system: May connect the charger with a vehicle, network, monitoring platform, or payment system.

• Metering: Measures electrical energy where required.

India's Ministry of Power 2024 guidelines apply to EV charging infrastructure in private, semi-restricted, public, highway, and expressway locations.

Main Types of EV Chargers

AC chargers supply alternating current to the vehicle, with the vehicle's onboard charging system generally handling the conversion to battery-compatible direct current.

DC chargers perform the AC-to-DC conversion within the charging equipment and can deliver direct current to the vehicle battery through the appropriate charging interface.

Home chargers are generally designed for private residential locations and may use a dedicated electrical circuit.

Public chargers can have higher power ratings and may include communication, access control, metering, and multiple charging connectors.

Fleet chargers are designed for locations such as company vehicle depots, bus facilities, delivery fleets, or other areas where multiple vehicles are charged.

Importance

Providing the Correct Electrical Connection

An EV charger can place a significant electrical load on a building. The electrical supply, circuit capacity, wiring, protective equipment, and distribution arrangement therefore need to match the charger's requirements.

India's 2024 Ministry of Power guidelines state that owners of EV charging stations may opt for a Low Tension connection for loads up to 150 kW, subject to the applicable electricity-supply framework.

Supporting Electrical Safety

Charging equipment operates with substantial electrical energy. Proper protection against electric shock, overloads, short circuits, and other applicable faults is therefore an important part of installation planning.

BIS material for IS 17017 Part 1 includes requirements related to protection against electric shock, conductive electrical interfaces, cable assemblies, overload and short-circuit protection, construction, and marking.

Ensuring Vehicle Compatibility

Different vehicles can use different charging configurations. The charger, connector, voltage, current, communication method, and vehicle inlet must be compatible.

India's BIS standards for EV conductive charging cover EV supply equipment as well as plugs, socket-outlets, vehicle connectors, and vehicle inlets.

Supporting Reliable Operation

Correct installation helps the charger operate within its intended electrical conditions. Cable sizing, ventilation, environmental protection, grounding, mounting, and protective devices can all influence the installation.

The charger itself is only one part of the complete charging system.

Main Installation Components

Recent Updates

India's 2024 Charging Infrastructure Guidelines

The Ministry of Power issued the Guidelines for Installation and Operation of Electric Vehicle Charging Infrastructure-2024 in September 2024. They replaced earlier consolidated guidelines and cover private, semi-restricted, public, highway, and expressway charging locations.

The guidelines also address electricity connections, tariff arrangements, charging infrastructure, and the development of a connected and interoperable charging network.

For residential users, the 2024 framework allows use of an existing electricity connection for EV charging or a separate metered connection from the distribution licensee, subject to the applicable arrangement.

PM E-DRIVE Charging Infrastructure

The PM E-DRIVE program has introduced operational guidelines for deployment of public EV charging stations. The Ministry of Heavy Industries published operational guidelines for EV public charging stations in September 2025, followed by additional material and FAQs.

The related charging-infrastructure framework covers multiple EV categories, including electric two-wheelers, three-wheelers, cars, buses, and trucks.

Higher-Power Charging

Charging equipment is evolving toward higher power levels for larger vehicles and fleet applications.

A PM E-DRIVE draft guideline identifies minimum charger configurations for different vehicle segments, including 60 kW CCS Type-2 charging for electric four-wheelers and 240 kW CCS Type-2 charging for electric buses and trucks under the specified scheme framework.

Actual installation requirements depend on the applicable vehicle, charger, electrical supply, location, and program conditions.

New BIS Standards

BIS's conductive-charging standards continue to develop. Its 2025 compendium lists IS 17017 Part 30:2025 for dual-gun DC EV supply equipment. The standard covers equipment capable of supporting two charging connections under specified electrical conditions.

BIS records also show continuing review and testing activity around IS 17017 components and related EV charging standards.

Connected Charging Systems

Modern chargers increasingly include communication capabilities. Depending on the installation, these can support charger monitoring, usage information, remote status reporting, access control, or integration with a broader charging network.

Connected features require suitable communication infrastructure and cybersecurity considerations in addition to electrical installation.

Laws or Policies

Ministry of Power Guidelines

India's Ministry of Power is a central source for EV charging infrastructure guidelines. The 2024 guidelines apply across a wide range of charging locations, including private parking, offices, educational institutions, hospitals, housing societies, commercial locations, transport facilities, highways, and expressways.

These guidelines provide a national framework, while electrical installations may also be subject to applicable state electricity regulations, distribution-licensee requirements, building provisions, and other technical rules.

BIS Standards

BIS standards provide technical references for EV conductive charging equipment and its interfaces.

IS 17017 Part 1 covers general requirements for EV conductive charging systems, including systems connected to private or public electrical networks and certain on-site energy-storage arrangements.

Other parts address specific charging configurations, connectors, vehicle inlets, electromagnetic compatibility, and DC charging equipment.

Electrical Wiring

The electrical installation supporting an EV charger needs to follow applicable wiring and electrical-safety requirements. BIS documentation for one EV charging standard references IS 732:2019, the Indian code of practice for electrical wiring installations.

The exact wiring arrangement depends on the electrical supply, charger rating, cable length, installation environment, and applicable local requirements.

Electricity Connection

The 2024 national guidelines specify procedures and timelines related to electricity connections for EV charging infrastructure. They also address connection options for residential charging and charging-station loads.

Before installation, the available electrical capacity should therefore be checked with the applicable distribution utility and qualified electrical personnel.

Public Charging Programs

The PM E-DRIVE scheme provides a policy framework for deployment of selected public EV charging infrastructure. Its operational guidelines specify eligibility and technical requirements for charging infrastructure supported under the program.

Tools and Resources

Electrical Testing Instruments

Installers may use electrical testing instruments to verify the installation before energization.

Common examples include:

• Multimeter: Measures selected electrical quantities such as voltage and resistance.

• Clamp meter: Measures current without disconnecting the conductor in many situations.

• Insulation tester: Checks insulation resistance.

• Earth-resistance tester: Assesses selected earthing-system characteristics.

• Voltage tester: Helps verify the presence or absence of voltage.

• Phase-sequence tester: Checks phase sequence in applicable three-phase systems.

The appropriate instruments and test procedures depend on the installation and applicable electrical requirements.

Cable Installation Tools

Cable preparation can require cutters, crimping tools, cable glands, lug tools, conduit tools, pulling equipment, and fastening hardware.

The correct tools help maintain reliable electrical connections and protect cable insulation during installation.

Mounting Equipment

Wall-mounted chargers may require anchors, brackets, drilling equipment, levels, fasteners, and suitable weather-resistant enclosures.

Pedestal installations can require a foundation, mounting structure, underground conduit, and protection against accidental vehicle impact.

Protection Equipment

Circuit breakers, residual-current protection, surge protection, isolation equipment, fuses, and other protective devices may be incorporated according to the charger design and applicable electrical requirements.

The exact protection arrangement should be determined from the charger manufacturer's specifications and applicable electrical standards.

Cable and Conduit Planning

Cable selection depends on factors such as current rating, conductor material, cable length, installation method, temperature, voltage drop, and environmental conditions.

Outdoor installations may also require protection from water, sunlight, physical damage, and vehicle movement.

Documentation

Installation documentation can include:

• Electrical single-line diagrams

• Charger specifications

• Circuit schedules

• Cable information

• Test records

• Earthing records

• Equipment manuals

• Maintenance instructions

• Applicable approval or inspection documents

Keeping these records can help with future inspection, troubleshooting, maintenance, or system modification.

FAQs

What is EV Charger Installation Equipment?

EV Charger Installation Equipment includes chargers, cables, protective devices, distribution equipment, connectors, earthing components, mounting hardware, testing instruments, and related installation materials.

What equipment is needed to install an EV charger?

A typical installation may require an EV charger, suitable electrical cable, circuit protection, earthing components, conduit or cable protection, mounting hardware, connectors, and electrical testing equipment. The exact list depends on the charger and installation location.

Can an EV charger use a normal household electrical connection?

Some residential charging arrangements can use an existing electricity connection, subject to the charger's electrical requirements and applicable rules. India's 2024 Ministry of Power guidelines specifically address residential charging through existing or separate metered connections.

What safety equipment is needed for EV charger installation?

The installation may require appropriate circuit protection, earthing, isolation, residual-current protection, surge protection, and other measures depending on the charger and electrical system. Qualified electrical personnel should determine the applicable arrangement.

What are the main EV charger standards in India?

The IS 17017 series is a major group of Indian Standards covering electric vehicle conductive charging systems, including general requirements, connectors, vehicle inlets, AC charging, DC charging, and other configurations.

Conclusion

EV Charger Installation Equipment includes much more than the charger itself, covering electrical protection, cables, connectors, mounting hardware, earthing, testing instruments, and supporting infrastructure. Proper installation requires compatibility between the vehicle, charger, electrical supply, protective equipment, and physical location. India's 2024 Ministry of Power guidelines and the BIS IS 17017 series provide important references for EV charging infrastructure and equipment. Recent developments under PM E-DRIVE and newer BIS standards are also supporting the expansion and technical development of charging infrastructure.
